Square Lock Screw Bolt Fasteners Nut Hydraulic Nuts M8 Carbon Steel
Product Details:
| Place of Origin: | China |
| Brand Name: | Liangru |
| Certification: | CE ISO |
| Model Number: | OEM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | film or plywood package suit for shipping |
| Delivery Time: | 15-20days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Pcs /month |
|
Detail Information |
|||
| Finishing: | Galvanized, Nickel Plated | Standard: | ISO |
|---|---|---|---|
| Size: | 45 -m8 | Application: | Automotive Industry, General Industry, Heavy Industry |
| Material: | Carbon Steel | OEM: | YES |
| Highlight: | Hydraulic Nuts M8,Square Lock Screw Bolt Fasteners,Hydraulic Nuts Carbon Steel |
||
Product Description
Square Lock Screw Bolt Fasteners Nut M8 Carbon Steel Hydraulic Coupling Flat Head T Slot Sliding Nut
Commonly used in bearings, flywheels, propellers and other workpiece presses hydraulic tools. With the resulting top thrust is smooth, no impact, the process does not hurt the workpiece and other characteristics. Through the hydraulic nut inner thread, which can be installed in the shaft parts, the piston under the action of 700bar hydraulic pressure to push the workpiece to the installation position.
Features:
1. Suitable for high temperature of 100℃.
2. Provide special seal when temperature is higher than 100℃.
3. Anti corrosion protective cap.
4. Spherical washers can be used if the interface is not at right angles.
Specifications:
|
Products name
|
Hydraulic Coupling Flat Head T Slot Anchor Self Locking M8 T Nut
|
|
Size
|
45 -m8
|
|
Material
|
Carbon steel
|
|
Processing
|
Raw materials - inspection - cold forging machining - inspection - mechanical punching and tapping - inspection - electroplating -
inspection - packaging - inspection -packaging - delivery |
|
Surface Finishing
|
Zn- Plated,Sandblast and Anodize,Chromate, Polish, Electro Painting, Black Anodize, Plain,etc
|
|
Heat Treatment
|
Tempering, Hardening, Spheroidizing, Stress Relieving,etc
|
|
Standard
|
GB, DIN, ISO, ANSI/ASTM, BS, BSW, JIS etc
|
|
Package
|
Plastic bag / small box +outer carton +pallets
|
|
Lead Time
|
7-15 working days as usual,It will based on the detailed order quantity.
|
|
Bolt Diameter (mm) |
Working Pressure (MPa) |
Max. Load (KN) |
Outside Diameter (mm) |
Height (mm) |
Stroke (mm) |
| M33 | 150 | 216 | 74 | 64 | 6 |
| M36 | 150 | 246 | 80 | 71 | 4 |
| M39 | 150 | 296 | 87 | 75 | 4 |
| M42 | 150 | 340 | 94 | 81 | 6 |
| M45 | 150 | 406 | 101 | 88 | 6 |
| M48 | 150 | 457 | 107 | 89 | 8 |
| M52 | 150 | 553 | 117 | 96 | 8 |
| M56 | 150 | 656 | 128 | 100 | 8 |
| M64 | 150 | 817 | 144 | 113 | 10 |
| M68 | 150 | 1008 | 157 | 119 | 10 |
| M72 | 150 | 1051 | 163 | 123 | 12 |
| M80 | 150 | 1459 | 187 | 142 | 12 |
| M90 | 150 | 1727 | 207 | 158 | 12 |
| M95 | 150 | 1965 | 219 | 166 | 12 |
| M100 | 150 | 2233 | 234 | 172 | 15 |
| M110 | 150 | 2688 | 255 | 184 | 15 |
| M125 | 150 | 3636 | 296 | 210 | 15 |
| M140 | 150 | 4371 | 328 | 238 | 15 |
| M150 | 150 | 5268 | 356 | 255 | 18 |
FAQ:
3. Q: Are you a factory or a trading company?
A: We are a professional factory who gets 20+ years of professional experience
5. Q: How long is your warranty?
A: Within 1 year from the date of the factory, if parts are a failure or are damaged the cause of a quality problem (except wearing parts), we provide these parts for free.
